Press the Set Button so that the screen lights up

Then press the Mode & Set buttons at the same time for about 3 seconds until the SP parameter screen is entered.

Now you can use the Plus & Minus buttons to change the setting and the Set button saves it to memory.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

Press the Set Button so that the screen lights up

Then press the Mode & Set & Minus buttons at the same time for about 5 seconds until the RP parameter screen is entered.

Then press the MODE button 2 times to get to the MS parameter screen.

Now you can use the Plus & Minus buttons to change the setting and the Set button saves it to memory.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

Press the Set Button so that the screen lights up

Then press the Set & Minus buttons at the same time for about 3 seconds until the CT parameter screen is entered.

Then press the MODE button 3 times to get to the LA parametr screen.

Now you can use the Plus & Minus buttons to change the setting and the Set button saves it to memory.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

Press the Set Button so that the screen lights up

Then press the Mode & Set & Minus buttons at the same time for about 5 seconds until the RP parameter screen is entered.

Now you can use the Plus & Minus buttons to change the setting and the Set button saves it to memory.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

1) Remove the filling plug

2) Fill the pump with water

3) Refit the filling plug

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

The product is made and supplied with the capacity of being self-priming.

However there are cases in which the self-priming capacity is not necessary to use self-priming pumps. During priming the pump obliges part of the water already under pressure to return to the suction part until a pressure value is reached at delivery whereby the system can be considered primed.

At this point the recirculating channel closes automatically. This phase is repeated each time the pump is switched on, even already primed, until the same pressure value that closes the recirculating channel is reached about 14psi (1 bar).

When the water arrives at the system intake already under pressure, it is possible to force the closure of the recirculating pipe, losing the self-priming capacity.

This obtains the advantage of eliminating the clicking noise of the pipe shutter each time the system is switched on.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.

The system has an integrated check valve (NRV) which is necessary for the pump to work correctly.  The there is a presence of solid bodies or sand in the water this could cause the valve to stick and cause a malfunction in the system. Even if as recommended you only use clean water and or fit a filters on input over time it is possible for the check valve to stick, so if you notice abnormal operation of the non-return valve it can be extracted from the system and cleaned and/or replaced.

To learn more about this topic, you can register free for our online course E.syline organized by D.Training, aimed at installers, plumbers or interested people. We recommend you read the E.sybox Mini 3 instruction manual (also available on our DNA software) for all information on the use of the product.
